BEAs MS51 is a long-lasting battery-powered, active infrared touchless actuator that reduces wiring and provides flexible mounting options. It may be hardwired or connected to wireless transmitters. This solution boasts superior battery life with three years of
uninterrupted operation across a range of applications and environments. LED alerts indicate battery status for easy maintenance.
10MS51-D BEA Touchless Actuator
Touchless Actuator, Battery-Powered, Double Gang, “Wave To Open”, Hand Logo, Stainless Steel Finish
$364.64
Buy Now
This item: 10MS51-D BEA Touchless Actuator
$364.64
$364.64
| TECHNOLOGY/PERFORMANCE | |
|---|---|
| TECHNOLOGY NUMBER OF IR SENSORS | Active Infrared 2 |
| DETECTION RANGE | 8” (20cm) max. |
| BATTERY LIFE | 3 years (at 150 activations per day) |
| PRODUCT TEMPERATURE RANGE | -22 – 158 °F (-30 – 70 °C) |
| ELECTRICAL | |
| OUTPUT MAX. SWITCHING VOLTAGE MAX. SWITCHING CURRENT | 1 electronic relay (galvanic isolation - polarity free) 42 VAC/VDC 100 ma |
| POWER SUPPLY | 3 VDC (2 AA batteries, each ~1.5 V max.) |
| POWER CONSUMPTION | < 0.5 mW (when idle) < 12 mW (upon activation) |
| WIRE GAUGE | 26-16 AWG |
| PHYSICAL | |
| DIMENSIONS SINGLE GANG DOUBLE GANG ROUND JAMB | 2 ¾” (W) × 4 ½” (H) × 1 ¼” (T) 4 ½” (W) × 4 ½” (H) × 1 ¼” (T) 6” (H/W) × 1 ¼” (T) 1 ¾” (W) × 4 ½” (H) × 1 ¼” (T) |
| MATERIAL | Stainless steel 304 and PC |
| WEIGHT | 1 lb |
| COMPLIANCE | |
| IP RATING | IP65 |
Downloads
| Weight | 1 lbs |
|---|
