| Model |
NVR516‑64E‑R |
NVR516‑128E‑R |
| Decoding |
| Decoding Format |
Ultra 265, H.265, H.264 |
| Decoding Capability |
2 x 32MP@30, 4 x 16MP@30, 5 x 12MP@30, 8 x 4K@30, 12 x 5MP@30, 16 x 4MP@30, 20 x 3MP@30, 32 x 1080P@30, 54 x 960P@30, 64 x 720P@30 |
2 x 32MP@30, 4 x 16MP@30, 5 x 12MP@30, 8 x 4K@30, 12 x 5MP@30, 16 x 4MP@30, 20 x 3MP@30, 32 x 1080P@30, 54 x 960P@30, 72 x 720P@30, 128 x D1 |
| Decoding Capability Description |
The resolution of each channel cannot exceed 8640 pixels in length or width, For VGA/HDMI independent output, the VGA live video is output by default. To output the highest resolution video from the HDMI port, please clear the VGA video on the preview page. |
| Audio Compression |
G.711A, G.711U |
| Network |
| Incoming Bandwidth |
640Mbps |
| Outgoing Bandwidth |
640Mbps |
| Remote Users |
128 |
| Protocols |
TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, NFS, RTSP, 802.1x, IPv6, IPv4 |
| Browser(Plugin) |
IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+ |
| Video/Audio Input |
| IP Video Input |
64‑ch |
128‑ch |
| RCA Audio Input |
1‑ch |
| Video/Audio Output |
| HDMI Output |
HDMI1: 8K (7680 × 4320)/30 Hz, 4K (3840 2160)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz; HDMI2: 4K (3840 × 2160)/60 Hz, 1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
| VGA Output |
1920 × 1080/60 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz |
| RCA Audio Output |
2‑ch |
| Liveview Display |
1/4/6/8/9/16/25/36/64 |
| Corridor Mode Screen |
3/4/5/7/9/10/12/16/32 |
| Two‑way Audio |
| Two‑way Audio |
1‑ch, RCA (Using the audio input and output) |
| Snapshot |
| FTP/Schedule/Event Snapshot |
16‑ch snapshot (max. 8 MP (3840 × 2160) video resolution, with 1080P snapshot resolution) |
| Recording |
| Recording Resolution |
32 MP/16 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080P/960P/720P/D1/2CIF/CIF |
| Synchronous Playback in Local |
16‑ch |
| Smart |
| VCA Detection by IPC |
Face Detection, Vehicle Detection, SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area), Ultra Motion Detection (UMD), Temperature Detection (Fire Detection, Smoking Detection, Temperature Measurement, Smoke and Fire Detection), People Counting (People Flow Counting, Crowd Density Monitoring), Video Metadata, Traffic Monitoring |
| VCA Search |
Face Snapshot Search, Motor Vehicle Search, Non‑Motor Vehicle Search, Human Body Search, General Search, People Counting Report, Heat Map |
| Smart by IPC |
All channels (up to 32 images/s in total)Face Detection, Vehicle Detection, Temperature Detection, SIP, UMD, Video Metadata, Traffic Monitoring |
| Alarm |
| General Alarm |
Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection |
| Alert Alarm |
IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal |
| GUI Language |
| GUI Language |
38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian |
| Hard Disk |
| SATA |
16 SATA Interfaces |
| Capacity |
Up to 16 TB for each HDD (The maximum HDD capacity varies with environment temperature) |
| Disk Group |
Support |
| Redundant Storage |
Support |
| Disk Array Type |
RAID 0, 1, 5, 6, 10, 50, 60 |
| Hot Swap |
Support |
| External Interface |
| Network Interface |
2 RJ45 10 M/100 M/1000 M self‑adaptive Ethernet Interface |
| USB |
Front panel: 2 × USB2.0, Rear panel: 2 × USB3.0 |
| RS485 |
1 |
| RS232 |
1 |
| Alarm In |
16‑ch |
| Alarm Out |
10‑ch |
| eSATA |
1 |
| Power Output |
12 V |
| Power Supply |
AC 100 to 240 V |
| Power Switch |
Support |
| Redundant Power Supply |
Support |
| Working Environment |
| Working Temperature |
‑10 ℃ to 55 ℃ (14 ℉ to 131 ℉) |
| Working Humidity |
≤ 90% RH (non‑condensing) |
| Power Consumption (without HDD) |
≤ 50W |
| Dimensions |
| Weight (without HDD) |
≤ 6.5Kg (14.3lb) |
| Height |
3U |
| Dimensions |
482mm × 533mm × 131mm (19.0"×21.0"×5.1") |
| Certification |
| Certification |
CE; FCC; UL; RoHS; WEEE |
| CE |
EN 55032, EN 61000‑3‑3, EN IEC 61000‑3‑2, EN 55035 |
| FCC |
Part15 Subpart B |
