Speco O4D9M 4MP Vandal Resistant Dome IP Camera with Advanced Analytics and Junction Box, 2.8-12mm Motorized Lens,
Supports up to 4MP at 30 fps
4x Optical Zoom
Two-way Audio
$361.49
Product Overview
4MP H.265 IP Dome Camera with Advanced Analytics 2.8-12mm motorized lens, white housing.
Main Features
- Supports up to 4MP at 30 fps
- 4x Optical Zoom
- Two-way Audio Support
- Built-in standard PoE (IEEE 802.3af)
- H.265/H.264/MJPEG compression supported
- True Day/Night operation (IR cut filter)
- Adaptive IR LEDs reduce IR saturation
- IR range Up to 165 FT (depending on scene reflection)
- Micro SD slot up to 256GB (card not included)
- True WDR (wide dynamic range) operation
| Specifications | |||||||||||||||||||||||
| Part Number | O4D9M | NDAA Compliant | Yes | Packaged Quantity | 12 | Product Line | AI line | Product Model | O4D9M | Product Name | O4D9M | Product Series | AI line | ||||||||||
| Technical Information | |||||||||||||||||||||||
| Effective Camera Resolution | 4MP | Field of View | Horizontal: 100° to 28.9° Vertical: 54.5° to 16.7° Diagonal: 104.8° to 33.1° | HD Recording | Yes | Lens Mount Type | 14 mm | Lens Type | Motorized | Maximum Aperture | F1.6 | Maximum Frame Rate | 30 fps | Minimum Focal Length | 2.8 mm | Night Vision | Yes | Night Vision Type | IR | Number of IR LEDs | 3 | Optical Zoom | 4x |
| Audio | |||||||||||||||||||||||
| Shipping (Inner) Case Gross Weight (g) | 1896 | Shipping (inner) Case Net Weight (g) | 1896 | ||||||||||||||||||||
| Camera | |||||||||||||||||||||||
| Night Vision Distance | 164' | Wide Dynamic Range | Yes | ||||||||||||||||||||
| Display & Graphics | |||||||||||||||||||||||
| Color Supported | Color, Monochrome | Maximum Video Resolution | 4MP | Number of Sensors | 100% | ||||||||||||||||||
| Environmental Conditions | |||||||||||||||||||||||
| Maximum Operating Temperature | 140°F | Minimum Operating Temperature | -22°F | Operating Humidity | >95 % (non-condensing) | ||||||||||||||||||
| Exposure | |||||||||||||||||||||||
| Longest Shutter Speed | 1/3s | Minimum Illumination | 0.005 lux | Shortest Shutter Speed | 1/100000 s | ||||||||||||||||||
| Interfaces/Ports | |||||||||||||||||||||||
| Network (RJ-45) | Yes | ||||||||||||||||||||||
| Lens | |||||||||||||||||||||||
| Focal Length | 2.8-12 mm | Lens Included | Yes | Maximum Focal Length | 12 mm | ||||||||||||||||||
| Network & Communication | |||||||||||||||||||||||
| Remote Management | Yes | ||||||||||||||||||||||
| Physical Characteristics | |||||||||||||||||||||||
| Color | White | Depth | 6" | Durability | Dustproof, Impact Resistant, Waterproof | Form Factor | Dome | Package Type | Box | Weight (Approximate) | 2.05 lb | Width | 6" | ||||||||||
| Power Description | |||||||||||||||||||||||
| Input Voltage | 12 V DC | ||||||||||||||||||||||
| Product Information | |||||||||||||||||||||||
| Mount Type | Ceiling Mount, Pole Mount, Wall Mount | ||||||||||||||||||||||
| Video | |||||||||||||||||||||||
| Analog Video Signal Format | CVBS | Horizontal Resolution | 2592 | ||||||||||||||||||||
| Miscellaneous | |||||||||||||||||||||||
| Environmental Certification | EC, EU RoHS, REACH, WEEE | Environmentally Friendly | Yes | Impact Protection Rating | IK10 | Indoor/Outdoor | Indoor, Outdoor | Ingress Protection Rating | IP67 | Package Contents | Camera, Screws, QSG, CD, Drill Template, Junction Box | ||||||||||||
| Weight | 3 lbs |
|---|---|
| Dimensions | 5.61 × 5.61 in |
