Name: LifeSafetyPower FPO150-2C8P2D8PE6S Software House Unified Power Systems 150W Single Voltage, 120 VAC 16 Relay Lock Outputs 16 Auxiliary Outputs
SKU: FPO150-2C8P2D8PE6S
Availability: InStock

Software House Unified Power Systems combine FlexPower power modules alongside access control hardware in one compact and secure UL listed solution. Unified Power features include:

Built in Fire Alarm disconnect unlocks doors on a fire alarm
Low battery cutoff protects batteries from deep discharge
Dedicated fast charger prolongs battery life
Enhanced surge immunity for input/output protection
Locksafe optimized voltages provide long-term lock protection
OutSmart Visual LED notification (12V/Green, 24V/Blue)
Network ready with optional LifeSafety Power NetLink® module
- Monitor power supply and battery in NetLink dashboard
- Remote test batteries
Lifetime Warranty LifeSafety Power’s quality commitment

1 x FPO150 150W Total Output, 120 VAC Input, AC Fault and System Fault form C contacts may be triggered by low/no battery, short to earth ground, power supply failure, or blown fuse
2 x C8P (16 Relay Lock Outputs) 2.5A Class 2 power limited outputs, programmable for failsafe/failsecure, FAI, NC/NO input, voltage or dry output per zone. Dual buss voltage selection by zone, OutSmart dual color LEDs
2 x D8P (16 Auxiliary Outputs) 2.5A Class 2 Power Limited Outputs, dual buss voltage selection by zone, OutSmart dual color LEDs
E6S Enclosure Size: 30.0H x 23.0W x 6.5D in (76.20 x 58.42 x 16.51 cm)
- Enclosure E6
- Backplate E6S
System Weight 44.40 lbs (20.14kg)

Weight	50 lbs
