LifeSafetyPower FPG100-D8PE2M1 Mercury Unified Power Systems 100W Single Voltage, Universal 8 Auxiliary Outputs
$810.92
Mercury Unified Power Systems combine FlexPower power modules alongside access control hardware in one compact and secure UL listed solution. Unified Power features include:
- Built in Fire Alarm disconnect unlocks doors on a fire alarm
- Low battery cutoff protects batteries from deep discharge
- Dedicated fast charger prolongs battery life
- Enhanced surge immunity for input/output protection
- Locksafe optimized voltages provide long-term lock protection
- OutSmart Visual LED notification (12V/Green, 24V/Blue)
- Network ready with optional LifeSafety Power NetLink® module
- Monitor power supply and battery in NetLink dashboard
- Remote test batteries
- Lifetime Warranty LifeSafety Power’s quality commitment
- 1 x FPG100 100W Total Output, Universal Input, AC Fault and System Fault form C contacts may be triggered by low/no battery, short to earth ground, power supply failure, or blown fuse
- 1 x D8P (8 Auxiliary Outputs) 2.5A Class 2 Power Limited Outputs, dual buss voltage selection by zone, OutSmart dual color LEDs
- E2M1 Enclosure Size: 20.0H x 16.0W x 4.5D in (50.80 x 40.64 x 11.43 cm)
- Enclosure E2M1
- Backplate E2M1
- System Weight 18.40 lbs (8.35kg)
Electrical RatingsParameterRatingInput VoltageUniversal Input, 100-240 VAC,50/60HzInput Power (max)153WOutput Power100WAuxiliary Outputs8 @ 2.5A Class 2 Power LimitedMaximum Charge CurrentFPG100: 1.1A, 40AH maximumLow Power Disconnectat 70% of battery voltageSystems BTU/Hr85 BTU/HrOperating Temperature32 to 122F (0 to +50C)Efficiency81% 120VAC 60Hz In, Full LoadAgency ApprovalsFCC Part 15, Subpart B IEC 62368-1:2014, EN 55032:2015, EN6100-3-2:2014, EN6100-3-3:2013, EN55024:2010+A1:2015, BIS IS13252(Part 1):2010, REACH 209, ROHS 3, RCM AS/NZS 4417.1, SAA AS/NZS 62368.1:2018, PSE J62368-1(2020), PSE J55032(H29)
| Weight | 20 lbs |
|---|
