LifeSafetyPower FPG100/100-D8M8NL4E6S Software House Unified Power Systems 200W Dual Voltage, Universal 8 Managed Lock Outputs 8 Auxiliary Outputs

$2,226.90

Buy Now
SKU:FPG100/100-D8M8NL4E6S

Software House Unified Power Systems combine FlexPower power modules alongside access control hardware in one compact and secure UL listed solution. Unified Power features include:

  • Built in Fire Alarm disconnect unlocks doors on a fire alarm
  • Low battery cutoff protects batteries from deep discharge
  • Dedicated fast charger prolongs battery life
  • Enhanced surge immunity for input/output protection
  • Locksafe optimized voltages provide long-term lock protection
  • OutSmart Visual LED notification (12V/Green, 24V/Blue)
  • Network ready with optional LifeSafety Power NetLink® module
    • Monitor power supply and battery in NetLink dashboard
    • Remote test batteries
  • Lifetime Warranty LifeSafety Power’s quality commitment
  • 2 x FPG100 200W Total Output, Universal Input, AC Fault and System Fault form C contacts may be triggered by low/no battery, short to earth ground, power supply failure, or blown fuse
  • 1 x D8 (8 Auxiliary Outputs) 3A fused Outputs, dual buss voltage selection by zone, OutSmart dual color LEDs
  • 1 x M8 (8 Managed Lock Outputs) 3A fused outputs, programmable for failsafe/failsecure, remote power cycle, monitor voltage and current on each output, programmable limits, dual buss voltage selection by zone, cycle count by zone, bi-color output LEDs verify voltage setting
  • 1 x NL4 NetLink Module Provides remote monitoring of power supply and battery set, remote battery testing, temperature monitoring, tamper switch monitoring, email/SNMP alerts on faults, compatible with MSM Enterprise
  • E6S Enclosure Size: 30.0H x 23.0W x 6.5D in (76.20 x 58.42 x 16.51 cm)
    • Enclosure E6
    • Backplate E6S
  • System Weight 42.60 lbs (19.32kg)
Weight 50 lbs
