Hanwha XND-6080RV X-Series 2MP IR Indoor Vandal Dome Camera, 2.8-12mm Varifocal Lens, White (Replaces
Max. 2MP (1920 x 1080) resolution
2.8 ~ 12 mm (4.3x) motorized varifocal lens
Max. 60 fpsatall resolutions
$961.55
Product Overview
X series features the most powerful chipset ever incorporated into a full camera range. Hanwha’s self-developed 5 chip uses an all-new architecture that enables faster processing. This means the highest quality video performance with essential features suited to a wide range of video surveillance applications.
Main Features
- Max. 2MP (1920 x 1080) resolution
- 2.8 ~ 12 mm (4.3x) motorized varifocal lens
- Max. 60 fpsatall resolutions (H.265/H.264)
- H.265, H.264, MJPEG codec supported, multiple streaming
- Day & Night (ICR), WDR (150dB), Defog
- Loitering, directional detection, fog detection, audio detection, digital auto tracking, sound classification, tampering
- Motion detection, Handover
- SD/SDHC/SDXC memory slot (Max. 512GB)
- Hallway view, WiseStreamII support
- IR viewable length 30m, IK08
| Specifications | |||||||||||||||||||||||||||
| Part Number | XND-6080RV | NDAA Compliant | Yes | Product Line | Wisenet | Product Model | XND-6080RV | Product Name | 2MP Network IR Dome Camera | Product Series | X | Product Type | Network Camera | Weight (Approximate) (g) | 724 | ||||||||||||
| Technical Information | |||||||||||||||||||||||||||
| Connectivity Technology | Wired | Effective Camera Resolution | 2MP | Field of View | H : 119.5° ~ 27.9° / V : 62.8° ~ 15.7° / D : 142.1° ~ 32.0° | HD Recording | Yes | Lens Mount Type | Board Mount | Lens Type | Varifocal | Maximum Aperture | f/1.4 | Maximum Focal Length (mm) | 12 | Maximum Frame Rate | 60 fps | Minimum Focal Length | 2.8 mm | Night Vision | Yes | Night Vision Type | Infrared | Optical Zoom | 4.3x | Power Consumption (PoE) (W) | 15 |
| Camera | |||||||||||||||||||||||||||
| Night Vision Distance | 98.43 ft | Night Vision Distance (mm) | 30000 | Wide Dynamic Range | Yes | ||||||||||||||||||||||
| Display & Graphics | |||||||||||||||||||||||||||
| Color Supported | Color | Maximum Video Resolution | 1600 x 1200 | Minimum Illumination (lux) | 1.50E-02 | ||||||||||||||||||||||
| Environmental Conditions | |||||||||||||||||||||||||||
| Maximum Operating Temperature | 131°F (55°C) | Maximum Operating Temperature (°F) | 131 | Minimum Operating Temperature | 14°F (-10°C) | Minimum Operating Temperature (°F) | 14 | Operating Humidity | 90% | ||||||||||||||||||
| Exposure | |||||||||||||||||||||||||||
| Longest Shutter Speed | 2 Second | Shortest Shutter Speed | 1/12000 Second | ||||||||||||||||||||||||
| Interfaces/Ports | |||||||||||||||||||||||||||
| Network (RJ-45) | Yes | ||||||||||||||||||||||||||
| Lens | |||||||||||||||||||||||||||
| Focal Length | 2.8-12 mm | Lens Included | Yes | Maximum Focal Length | 12 mm | Minimum Aperture | f/3.6 | ||||||||||||||||||||
| Network & Communication | |||||||||||||||||||||||||||
| Remote Management | Yes | ||||||||||||||||||||||||||
| Others | |||||||||||||||||||||||||||
| Physical Characteristics | |||||||||||||||||||||||||||
| Color | White | Color Family | White | Form Factor | Dome | Height | 4.4" | Product Color | Ivory | Weight (Approximate) | 1.60 lb | ||||||||||||||||
| Power Description | |||||||||||||||||||||||||||
| Input Voltage | 12V DC | ||||||||||||||||||||||||||
| Product Information | |||||||||||||||||||||||||||
| Diameter | 5.5" | Mount Type | Corner Mount, Pole Mount, Wall Mount | ||||||||||||||||||||||||
| Projection Lens | |||||||||||||||||||||||||||
| Minimum Focal Length (mm) | 2.8 | ||||||||||||||||||||||||||
| Storage | |||||||||||||||||||||||||||
| Recording Formats | Full HD | Storage Type | Memory Card | ||||||||||||||||||||||||
| Video | |||||||||||||||||||||||||||
| Maximum Frame Rate (fps) | 60 | ||||||||||||||||||||||||||
| Warranty | |||||||||||||||||||||||||||
| Limited Warranty | 3 Year | ||||||||||||||||||||||||||
| Miscellaneous | |||||||||||||||||||||||||||
| Features | Back Light Compensation (BLC), Day/Night, Digital Image Stabilization, Digital Noise Reduction, Gain Control, Motion Detection, Privacy Masking, PTZ, SD Card Local Storage, White Balance | Impact Protection Rating | IK08 | Indoor/Outdoor | Indoor | ||||||||||||||||||||||
| Weight | 2 lbs |
|---|
