GRI 180RS-12 180RS Series 3/4″ Recessed Stubby Steel Door Switch Set, 5/8″ Gap, 10W, 200VDC, 0.50 Amp, Closed Loop,
Recessed magnetic contact
12†22 AWG leads or screw terminals
Available closed loop
$6.93
Product Overview
180RS and 8080RS-T SERIES Recessed 3/4″ and 1″ stubby steel door switch set.
Main Features
- Recessed magnetic contact
- 12″ 22 AWG leads or screw terminals
- Available closed loop only
- Longer leads, zip cord or jacketed cable upon request
- Built-in E.O.L. Resistors and Diodes Upon Request
- Colors available; white, brown, gray, black
- The MC-180 is designed to be mounted in the top channel of a metal entry/exit door
- Legs of the magnet case can be clipped to accommodate a more shallow channel
| Specifications | |||||||||||||||||||||||||||||
| Part Number | 180RS-12-W | Product Model | 180RS-12-W (WHITE) | Product Name | 180RS-12-W (WHITE) Magnetic Contact | Product Series | 180 | Product Type | Magnetic Contact | ||||||||||||||||||||
| Technical Information | |||||||||||||||||||||||||||||
| Connectivity Technology | Wired | Contact Configuration | N.O. | Contact Form | Form A | Contact Resistance | 150000 Micro Ohm | Contact Resistance (Ohm) | 0.15 | Lead Gauge | 0.87" | Lead Gauge (mm) | 22 | Lead Length | 12" | Lead Length (mm) | ## | Mounting Type | Recessed Mount | Power Consumption | 10W | Recommended Use | Door | Standard Gap | 0.63" | Standard Gap (mm) | 15.875 | Termination Style | Wire Leads |
| Physical Characteristics | |||||||||||||||||||||||||||||
| Application/Usage | Steel | Color | White | Diameter (mm) | 6.35 | Product Material | Steel | ||||||||||||||||||||||
| Power Description | |||||||||||||||||||||||||||||
| Input Current | 500 mA | Input Current (A) | 0.5 | Input Voltage | 200V DC | Input Voltage (V DC) | 200 | Power Consumption (W) | 10 | Power Source | DC | ||||||||||||||||||
| Product Information | |||||||||||||||||||||||||||||
| Contact Type | Closed Loop | Diameter | 0.3" | Installation Type | Commercial | ||||||||||||||||||||||||
| Warranty | |||||||||||||||||||||||||||||
| Limited Warranty | Lifetime | ||||||||||||||||||||||||||||
| Miscellaneous | |||||||||||||||||||||||||||||
| Features | End of Line (EOL) Resistor | ||||||||||||||||||||||||||||
