Solid bare copper conductors
Overall foil shield
Rated for riser and general purpose indoor
$199.49
Buy NowThis Genesis® cable features 2 solid 18 AWG copper conductors, an overall foil shield with a drain wire, and a riser rating. Choose this cable for a dependable fire alarm system wiring solution.
| Specifications | |||||||||||||||||||||||||
| Part Number | 44021104 | Packaged Quantity | 1 | Product Model | 44021104 | Product Name | 44021104 Control Cable | Product Type | Fire Alarm Cable | ||||||||||||||||
| Technical Information | |||||||||||||||||||||||||
| American Wire Gauge | 18AWG | Cable Listing | CL3R, FPLR, FT4, Sunlight Resistant | Cable Rating | Riser | Conductor Count | 200% | Connector on First End | Bare Wire | Connector on Second End | Bare Wire | Core/Cladding Diameter | 18/2 | Device Supported | Alarm, Fire Alarm | Jacket Material | PVC | Number of Conductors | 2 | Number of Pairs | 1 | Shielding | Yes | Solid or Stranded | Solid |
| Others | |||||||||||||||||||||||||
| ADI Part Number Replaces | WG-44025504 | Model Number Replaces | 44025504 | ||||||||||||||||||||||
| Physical Characteristics | |||||||||||||||||||||||||
| Cable Length | 1000' | Color | Red | Insulation Material | PP | Material | Bare Copper | Package Type | REELEX Pull Box | Weight (Approximate) | 17.40 lb | ||||||||||||||
| Warranty | |||||||||||||||||||||||||
| Limited Warranty | 3 Year; 3-for-1 | ||||||||||||||||||||||||
| Miscellaneous | |||||||||||||||||||||||||
| Environmental Certification | RoHS | Environmentally Friendly | Yes | Features | Stranded | Indoor/Outdoor | Indoor | TAA Compliant | Yes |
| Weight | 17.4 lbs |
|---|
