Fire-Lite SD365 Addressable Photoelectric Smoke Detector, LiteSpeed Only, White (Replaces
Two-wire SLC loop connection
Stable communication technique with noise i mmunity
Built-in tamper-resistant feature- functional test switch activated by external magnet-Walk test with address
$114.15
Product Overview
SD365 Series intelligent plug-in smoke detectors are designed for both performance and aesthetics. A new modern, sleek, contemporary design and enhanced optical sensing chamber is engineered to sense smoke produced by a wide range of combustion sources in accordance with more stringent code standards.
Main Features
- Two-wire SLC loop connection
- Stable communication technique with noise i mmunity
- Built-in tamper-resistant feature- functional test switch activated by external magnet- walk test with address display
- Removable cover and insect-resistant screen for simple field cleaning
- Low standby current
- Sealed against back pressure
- Separate base with SEMS screws for wiring allows interchange of photoelectric, ionization and thermal sensors, optional relay, isolator, and sounder bases
- Designed and to mount directly on the surface or the electrical box
- Factory preset at 1.5% nominal sensitivity for panel alarm threshold level
- LED blinks when the unit is polled (communicating with the fire panel) and latches in alarm
Specifications | |||||||
Part Number | SD365-P | Product Model | SD365-P | Product Series | SD365 | Product Type | Smoke Detector |
Technical Information | |||||||
Addressable | Yes | Connectivity Technology | Wired | Sensor Type | Photoelectric | ||
Physical Characteristics | |||||||
Color | White | ||||||
Miscellaneous | |||||||
Certifications | UL 2075, UL 268, UL 521 | UL Listed | Yes |
Weight | 2 lbs |
---|
