Product Overview
Our Sonic Vortex technology generates rich, deep bass and effortless clarity from what most people would call a ‘back box’, but is not. It is actually a compact, integrated tuned enclosure. This patented technology is a ‘twist’ on Ported Transmission Line design, that optimizes air movement to produce astonishing sound. The enclosure also keeps sound from bleeding to other rooms while adding 6 to 9dB boost in mid-lower bass.rial ceiling mount.
Main Features
- The 2-way speakers give smooth and precise production of sound to deliver an ultimate audio experience
- Handles up to 5W of RMS power
- Hear every detail crisp and clear with a frequency response of 38 Hz-22 kHz
- 8 Ohm impedance extracts maximum power so you will get more output from your speakers
| Specifications | |||||||||||||||||||||||||||||||
| Part Number | IC8-MB | Product Model | IC8-MB | Product Name | IC8-MB Speaker | Product Type | Speaker | Weight (Approximate) (g) | 3800 | ||||||||||||||||||||||
| Technical Information | |||||||||||||||||||||||||||||||
| Crossover Type | 2-way | Impedance | 8 ohms | Impedance (Ohm) | 8 | Maximum Frequency Response (Hz) | 22000 | Minimum Frequency Response (Hz) | 38 | PMPO Output Power (W) | 120 | Sensitivity | 90 dB | Sensitivity (dB) | 90 | Speaker Size | 8" | Tweeter Driver Material | Aluminum | Tweeter Driver Size | 1" | Tweeter Driver Size (mm) | 25.4 | Wireless Speaker | No | Woofer Driver Material | Injected Polypropylene | Woofer Driver Size | 8" | Woofer Driver Size (mm) | 203.2 |
| Audio | |||||||||||||||||||||||||||||||
| Maximum Frequency Response | 22 kHz | Minimum Frequency Response | 38 Hz | PMPO Output Power | 120W | RMS Output Power | 5W | RMS Output Power (W) | 5 | ||||||||||||||||||||||
| Physical Characteristics | |||||||||||||||||||||||||||||||
| Color | Black | Cutout Diameter | 10.30" | Cutout Diameter (mm) | 261.62 | Depth | 8.60" | Depth (mm) | 218.44 | Diameter (mm) | 287.02 | Form Factor | In-ceiling | Weight (Approximate) | 8.38 lb | Woofer Diameter | 8" | Woofer Diameter (mm) | 203.2 | ||||||||||||
| Product Information | |||||||||||||||||||||||||||||||
| Diameter | 11.3" | ||||||||||||||||||||||||||||||
| Warranty | |||||||||||||||||||||||||||||||
| Limited Warranty | Lifetime |
| Weight | 9 lbs |
|---|
