AXIS P5655-E 1080p HDTV PTZ WDR IP Camera, 32x Optical Zoom,
HDTV 1080p with 32x optical zoom
Forensic WDR and Lightfinder 2.0
Signed firmware and secure
$2,444.01
Product Overview
AXIS P5655-E PTZ Network Camera is a cost-effective high performance PTZ camera for versatile surveillance. Thanks to the newest generation of Axis chip, it offers excellent video quality, even in the most challenging light conditions, and a high level of defense to protect your system. It’s ideal for deterrent surveillance of large outdoor and indoor areas and provides great details when zooming in.
Great images – anytime
AXIS P5655-E offers superb image quality in HDTV 1080p with 32x optical zoom. It’s got Forensic WDR for clarity even when there’s both dark and light areas in the scene. And Lightfinder 2.0 for low-light images with more saturated colors and sharper images of moving objects. Additionally, it has electronic image stabilization (EIS) for stable images despite vibration. And focus recall gives you instant focus in challenging light conditions. Plus, it comes with four scene profiles (indoor, outdoor, forensic and traffic) with different image settings optimized to suit specific scenarios.
Keeping you secure
This PTZ camera is packed with enhanced security functionality to safeguard your system and prevent unauthorized access. Signed firmware and secure boot guarantees that the firmware hasn’t been altered and ensures only authorized firmware is installed. And if needed, secure boot guarantees that the camera is completely free of malware after a factory default.
And there’s more…
This versatile camera with IP66, NEMA 4X and IK10 ratings can handle temperatures ranging from -30°C to 50°C (-22°F to 122°F). Based on new generation chip, it offers extended processing power for handling of advanced analytics. And thanks to Axis Zipstream technology with H.264 and H.265 it preserves all the important details while significantly lowering bandwidth and storage requirements. It supports two-way audio, I/O ports, PoE+ and 24 V AC/DC.
Main Features
- HDTV 1080p with 32x optical zoom
- Forensic WDR and Lightfinder 2.0
- Signed firmware and secure boot
- Focus recall and EIS
- Zipstream with support for H.264 and H.265
Specifications | |||||||||||||||||||
Part Number | 01682-004 | NDAA Compliant | Yes | Product Line | P | Product Model | P5655-E | Product Name | P5655-E PTZ Network Camera | Product Series | P56 | Product Type | Network Camera | Weight (Approximate) (g) | 2500 | ||||
Technical Information | |||||||||||||||||||
Connectivity Technology | Wired | Effective Camera Resolution | 2MP | Field of View | Horizontal field of view: 58.3°- 2.4° - Vertical field of view: 35.5°- 1.4° | HD Recording | Yes | Lens Type | Varifocal | Maximum Aperture | f/1.4 | Maximum Focal Length (mm) | 137.6 | Maximum Frame Rate | 60 fps | Minimum Focal Length | 4.3 mm | Optical Zoom | 32x |
Camera | |||||||||||||||||||
Wide Dynamic Range | Yes | ||||||||||||||||||
Display & Graphics | |||||||||||||||||||
Color Supported | Color | Maximum Video Resolution | 1920 x 1080 | Minimum Illumination (lux) | 0.1 | ||||||||||||||
Environmental Conditions | |||||||||||||||||||
Maximum Operating Temperature | 122°F (50°C) | Maximum Operating Temperature (°F) | 122 | Minimum Operating Temperature | -22°F (-30°C) | Minimum Operating Temperature (°F) | -22 | Operating Humidity | 100% | ||||||||||
Exposure | |||||||||||||||||||
Longest Shutter Speed | 2 Second | Minimum Illumination | 0.1 lux | Shortest Shutter Speed | 1/66500 Second | ||||||||||||||
Interfaces/Ports | |||||||||||||||||||
Network (RJ-45) | Yes | ||||||||||||||||||
Lens | |||||||||||||||||||
Focal Length | 4.3-137.6 mm | Lens Included | Yes | Maximum Focal Length | 137.60 mm | Minimum Aperture | f/4 | ||||||||||||
Network & Communication | |||||||||||||||||||
Remote Management | Yes | ||||||||||||||||||
Others | |||||||||||||||||||
Physical Characteristics | |||||||||||||||||||
Color | White | Color Family | White | Diameter (mm) | 188 | Durability | Impact Resistant, Weather Resistant | Form Factor | Dome | Height | 8.5" | Height (mm) | 217 | Product Color | White | Weight (Approximate) | 5.51 lb | ||
Power Description | |||||||||||||||||||
Input Voltage | 100V AC, 240V AC | Input Voltage (V AC) | 100, 240 | ||||||||||||||||
Product Information | |||||||||||||||||||
Diameter | 7.4" | Mount Type | Bracket Mount, Ceiling Mount, Corner Mount, Pendant Mount, Pole Mount, Recessed Mount, Wall Mount | ||||||||||||||||
Projection Lens | |||||||||||||||||||
Minimum Focal Length (mm) | 4.3 | ||||||||||||||||||
Storage | |||||||||||||||||||
Recording Formats | Full HD | Storage Type | Memory Card | ||||||||||||||||
Video | |||||||||||||||||||
Maximum Frame Rate (fps) | 60 | ||||||||||||||||||
Warranty | |||||||||||||||||||
Limited Warranty | 5 Years | ||||||||||||||||||
Miscellaneous | |||||||||||||||||||
Features | Auto Gain Control, Automatic Defog, Cross Line Detection, Electronic Image Stabilization, HTTPS Encryption, Human Detection, Password Protection, Privacy Masking | Impact Protection Rating | IK10 | Indoor/Outdoor | Indoor, Outdoor | Ingress Protection Rating | IP66 | Package Contents | P5655-E PTZ Network Camera | ||||||||||
RJ45 Push-pull Connector (IP66) | |||||||||||||||||||
Hard ceiling mount | |||||||||||||||||||
Spring pipe adaptor | |||||||||||||||||||
U-profile pipe adaptor | |||||||||||||||||||
Installation Guide | |||||||||||||||||||
and more below | |||||||||||||||||||
, AVHS Authentication key, Windows decoder 1-user license | |||||||||||||||||||
Weight | 6 lbs |
---|
