APC SMT1500RM2UC Line Interactive Smart-UPS with SmartConnect Port/SmartSlot, 1500VA/1000W, NEMA 5-15R

$1,377.21

Buy Now
SKU:SMT1500RM2UC

Main Features

  • Cold-start capable – Provides temporary battery powerWhen the utility power is out.
  • Energy meter – Provides actual kiloW hours of usage for energy conscious users.
  • Green mode – Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
  • High online efficiency – Reduces utility costs, generates less heat.
  • Intelligent Card Slot – Mini slot supports various optional management cards which provide basic or essential monitoring, management and control features for the UPS.
  • Intuitive LCD interface – Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
  • Predictive replace battery date – Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
  • Pure sine wave output on battery – Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
  • Single switched outlet group – Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.
  • SmartConnect – Innovative, easy to use remote monitoring feature that provides automatic notifications, firmware updates, and advanced support services.
Specifications
Part Number SMT1500RM2UC Packaged Quantity 1 Each Product Line Smart-UPS Product Model SMT1500RM2UC Product Name Smart-UPS 1500VA LCD RM 2U 120V with SmartConnect Product Type Line-interactive UPS Weight (Approximate) (g) 26500
Technical Information
Load Capacity (VA) 1500VA Number of Batteries 1 Number of Battery & Surge Outlets 6 Output Voltage 110V AC, 120V AC, 127V AC Output Voltage (V AC) 110, 120, 127 Receptacle Detail 6 x NEMA 5-15R Receptacle Type NEMA 5-15P Transfer Time 10 ms Transfer Time (Second) 0.01 USB (HID Compliant) Port Yes
Battery Information
Battery Chemistry Lead Acid Battery Life 6 Year Battery Life (Second) 189341556 Output Voltage (V DC) 12, 24 Typical Battery Recharge Time 3-Hour Typical Battery Recharge Time (Second) 10800
Category Specific Attributes
Output Voltage (V) 12, 24 Surge Energy Rating (J) 680
Controls/Indicators
Status Indicators LCD Status
Environmental Conditions
Maximum Operating Elevation 10000 ft Maximum Operating Elevation (mm) 3048000 Maximum Operating Temperature 104°F (40°C) Maximum Operating Temperature (°F) 104 Maximum Storage Elevation 50000 ft Maximum Storage Elevation (mm) 15240000 Operating Humidity 0% - 95% Thermal Dissipation 65.94 W Thermal Dissipation (W) 65.941
Interfaces/Ports
Network (RJ-45) Yes Serial Port Yes
Management
Alarm Configurable Delay, Low Battery Network Management SmartSlot
Physical Characteristics
Color Black Color Family Black Depth 18.8" Depth (mm) 477 Form Factor Rack Mount Height 3.4" Height (mm) 86 Product Color Black Rack Height 2U Weight (Approximate) 58.42 lb Width 17" Width (mm) 432
Power Description
Input Frequency 60 Hz Input Frequency (Hz) 60 Input Voltage 120V AC Input Voltage (V AC) 120 Input Voltage Range 82 V AC - 144 V AC Output Frequency 60 Hz Plug/Connector Type NEMA 5-15P Surge Energy Rating 680 J Waveform Type Sine Wave
Product Information
Load Capacity (VA) (W) 1440 Load Capacity (W) 1440
Software
Software Included Powerchute Serial Edition
Warranty
Additional Warranty Information 3 years repair or replace (excluding battery) and 2 years for battery Limited Warranty 3 Year
Miscellaneous
Energy Star Yes Environmental Certification ENERGY STAR 2.0, REACH, RoHS Environmentally Friendly Yes Package Contents Smart-UPS 1500VA LCD RM 2U 120V with SmartConnect
Installation guide
Rack mounting support rails
Weight 58.42 lbs
