4 x RJ45 10M/100M Base-TX EthernetNetwork Port 1 Support POE (IEEE802.3af) OutputNetwork Port 4 Support PSE Voltage Test
Voltage Test
1 x PSE Voltage Test(PSE voltage detection Range： 1V~56V; IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt)
1 x DC voltage Test(DC voltage detection Range： 1V~56V)
Network
Wi-Fi
2.4G Wi-Fi (IEEE802.11b/g/n)
Structure / Environment
Battery Capacity
18650 lithium battery, 7500mAH
Power Input
1 x DC 5V/2A max, type-c
Power Output
1 x DC 12V/1A output; 1 x DC 5V/1A output, type-A
General
LED Indicator
System indicator, WiFi indicator, Battery indicator
Dimensions
130 × 85 × 33mm (5.1” × 3.3” × 1.3”) (L x W x H)
Working Environment
-20 °C ~ 60 °C (-4 °F ~ 140 °F), Humidity: ≤95% RH (non-condensing)
