Home›Cable›Tripp Lite N201-001-OR CAT6 Snagless Molded Gigabit Ethernet Cable, UTP, RJ45 M/M, 1′ (30.5cm),
Tripp Lite N201-001-OR CAT6 Snagless Molded Gigabit Ethernet Cable, UTP, RJ45 M/M, 1′ (30.5cm),
$2.70
Buy Now
Main Features
- Rated for 550 MHz/1 Gbps communications
- Snagless RJ45 connectors protect against broken tabs
- Meets Cat6 TIA/EIA standards
- High-quality 24 AWG stranded copper wire
- Reduces impedance and structural return loss
- Snagless design protects the locking tabs on the RJ45 connectors from being damaged or snapped off during installation
- PVC 4-pair stranded UTP
- Deliver stable performance up to 550MHz/1 Gbps communication
- Meets most current industry standards including IEEE 802.3ab, IEEE 802.5, ANSI/EIA/TIA 568, ISO/IEC 11801 and ETL (category 6 draft 11)
- Available in other colors and lengths
| Specifications |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| General Information |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Manufacturer Part Number |
N201-001-OR |
Packaged Quantity |
1 |
Product Model |
N201-001-OR |
Product Name |
Cat6 Gigabit Snagless Molded UTP Patch Cable (RJ45 M/M), Orange, 1 ft |
Product Series |
N201 |
Product Type |
Network Cable |
|
|
|
|
|
|
|
| Technical Information |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| American Wire Gauge |
24AWG |
Boot Type |
Snagless |
Cable Characteristic |
Patch Cable |
Cable Type |
Category 6 |
Connector on First End |
RJ45 |
Connector on Second End |
RJ45 |
Contact Plating |
Gold |
Device Supported |
Hub, Modem, Network Adapter, Network Device, Router, Server, Switch |
Frequency / Bandwidth Rating |
550 MHz |
Shielding |
No |
| Interfaces/Ports |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Connector Type |
RJ45 (MALE) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Media & Performance |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Data Transfer Rate |
1 Gbit/s |
Data Transfer Rate (Bps) |
134217728 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Physical Characteristics |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Cable Length |
1' |
Cable Length (mm) |
304.8 |
Color |
Orange |
Color Family |
Orange |
Material |
PVC |
Package Type |
Bulk |
Product Color |
Orange |
Product Material |
Copper |
|
|
|
|
| Warranty |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Limited Warranty |
Lifetime |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Miscellaneous |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Environmental Certification |
REACH, RoHS |
Environmentally Friendly |
Yes |
Features |
Booted, Crack Resistant, Crosstalk Protection, Damage Resistant, Flexible, Minimized Near-End Crosstalk (NEXT), Molded, Rugged, Strain Relief, Stranded, Stress Resistant |
|
|
|
|
|
|
|
|
All products in the Bargain Bin are final sale and are sold as is. No returns or exchanges are available for Bargain Bin items.
