Russound SS-4.2 Single Source Impedance Matching Speaker Selector for

$128.99

Buy Now
SKU:SS-4.2
The SS-4.2 allows you to switch up to four speaker pairs connected to a stereo amplifier. Offering high-quality audio performance, it also provides overload protection and long-term reliability. The SS-4.2 offers two operating configurations: Impedance Matching and Bypass. Impedance-matching mode provides automatic overload protection for use even with high-power amplifiers. This mode allows multiple pairs of speakers to be safely connected to an amplifier using the built-in automatic impedance-matching circuitry. Bypass mode is used for direct speaker switching with remote impedance-matching volume controls. This allows local control in each room as well as higher efficiency; however, in this mode the impedance matching and overload protection are not engaged. Designed for use with 8-ohm loudspeakers, the SS-4.2 also provides safe connection to bridged amplifiers and even works in applications where there is a floating ground. It has spring-loaded speaker terminals for quick connection and can accommodate speaker wire up to 12 gauge.

Main Features

  • Designed for high audio quality and long-term reliability
  • Provides impedance matching and automatic overload protection compatible with high-power Alifiers
  • Bypass mode allows direct speaker switching When using remote impedance-matching volume controls
Specifications
General Information
Part Number SS-4.2 Product Model SS-4.2 Product Name SS-4.2 Speaker Selector Product Series SS Product Type Speaker Selector
Technical Information
Device Supported Amplifier, Speaker
Interfaces/Ports
Audio Line In Yes Number of Inputs 2 Number of Outputs 4
Physical Characteristics
Color Black Depth 6.3" Depth (mm) 158.75 Height 1.8" Height (mm) 46.038 Width 8.5" Width (mm) 215.9
Warranty
Limited Warranty 10 Year
Weight 4 lbs
