Hanwha SCV-6085R 2MP Analog IR Vandal Dome Camera, 3.2-10mm Varifocal Lens,
Full HD (1,920 x 1,080 30 fps) resolution
0.11Lux (Color), 0Lux (B/W : IR LED on)
3.2 ~ 10 mm (3.1x) varifocal
$228.95
Product Overview
HD IR outdoor vandal-resistant dome cameras allow users to upgrade their surveillance systems to HD using legacy coax cabling without the costly process of ripping and replacing coax with Ethernet cabling. The new HD cameras offer a variety of high-performance features including Day/Night operation, motion detection, defog, IR illuminators and more depending on model. Models include box, indoor dome, outdoor vandal dome, and outdoor bullet. Setup functions are easily controlled by OSD with the built-in joystick or control over coaxial cable with HD DVRs. Low power consumption, compact form factors, and transmission up to 1,640 feet further enhance the lineup.
Main Features
- Full HD (1,920 x 1,080 30 fps) resolution
- 0.11Lux (Color), 0Lux (B/W : IR LED on)
- 3.2 ~ 10 mm (3.1x) varifocal lens
- Day & Night (ICR), Motion detection
- IR viewable length 30m (98.42ft)
- Transmission distance max. 500m
| Specifications | |||||||||||||||||||
| Part Number | SCV-6085R | NDAA Compliant | Yes | Product Model | SCV-6085R | Product Name | 2MP Analog IR Vandal Dome Camera | Product Series | HD+ | Product Type | Surveillance Camera | ||||||||
| Technical Information | |||||||||||||||||||
| Connectivity Technology | Wired | Effective Camera Resolution | 2MP | Field of View | H : 110.2°(Wide) ~ 32°(Tele) V : 55.4°(Wide) ~ 18°(Tele) D : 128.4°(Wide) ~ 36.6°(Tele) | HD Recording | Yes | Lens Type | Varifocal | Maximum Aperture | f/1.6 | Maximum Frame Rate | 30 fps | Minimum Focal Length | 3.2 mm | Night Vision | Yes | Optical Zoom | 3.1x |
| Camera | |||||||||||||||||||
| Night Vision Distance | 98.43 ft | Wide Dynamic Range | Yes | ||||||||||||||||
| Display & Graphics | |||||||||||||||||||
| Color Supported | Color | Maximum Illumination | 0.01 lux | Maximum Video Resolution | 1600 x 1200 | ||||||||||||||
| Environmental Conditions | |||||||||||||||||||
| Maximum Operating Temperature | 131°F (55°C) | Minimum Operating Temperature | -22°F (-30°C) | Operating Humidity | 90% | ||||||||||||||
| Exposure | |||||||||||||||||||
| Longest Shutter Speed | 1 Second | Shortest Shutter Speed | 1/12000 Second | ||||||||||||||||
| Lens | |||||||||||||||||||
| Focal Length | 3.2-10 mm | Lens Included | Yes | Maximum Focal Length | 10 mm | ||||||||||||||
| Physical Characteristics | |||||||||||||||||||
| Color | White | Color Family | White | Durability | Dustproof, Impact Resistant, Vandal Resistant, Waterproof | Form Factor | Dome | Product Color | Ivory | Weight (Approximate) | 1.58 lb | ||||||||
| Power Description | |||||||||||||||||||
| Input Voltage | 12V DC, 24V AC | ||||||||||||||||||
| Product Information | |||||||||||||||||||
| Diameter | 5.4" | Mount Type | Pendant Mount | ||||||||||||||||
| Storage | |||||||||||||||||||
| Recording Formats | HD | ||||||||||||||||||
| Video | |||||||||||||||||||
| Analog Video Signal Format | AHD, CVBS | ||||||||||||||||||
| Miscellaneous | |||||||||||||||||||
| Features | Alarm Triggering, Back Light Compensation (BLC), Built-in IR LED, Day/Night, Defog, Digital Noise Reduction, Digital Wide Dynamic Range (D-WDR), Highlight Compensation (HLC), Motion Detection, Privacy Masking, White Balance | Impact Protection Rating | IK10 | Indoor/Outdoor | Indoor, Outdoor | Ingress Protection Rating | IP66 | ||||||||||||
| Weight | 2 lbs |
|---|
