The Wisenet L series indoor dome camera provides excellent quality and value, featuring 2MP @ 30fps, 2.8mm fixed focal lens (113.7°), Double codec H.264/MJPEG, Wisestream II, 120dB WDR, IR LEDs, hallway view, SD card, PoE, white camera body.
Main Features
- 2MP (1920 x 1080) resolution
- Built-in 2.8 mm fixed lens
- 30 fpsat all resolutions (H.264)
- H.264, MJPEG codec supported, Multiple streaming
- Day & Night (ICR), WDR (120dB)
- Tampering, Motion detection
- Micro SD/SDHC memory slot (Max. 32GB), PoE
- Hallway view, WiseStream II support
- IR viewable length 20m
- White camera body
| Specifications | |||||||||||||||||||
| Part Number | LND-6012R | NDAA Compliant | Yes | Product Model | LND-6012R | Product Name | 2MP IR Dome Camera | Product Series | L | Product Type | Dome Camera | Weight (Approximate) (g) | 270 | ||||||
| Technical Information | |||||||||||||||||||
| Connectivity Technology | Wired | Effective Camera Resolution | 2MP | Field of View | H: 113.7°, V: 61.5°, D: 134.4° | HD Recording | Yes | Lens Type | Fixed Focus | Maximum Aperture | F2.0 | Maximum Focal Length (mm) | 2.8 | Maximum Frame Rate | 30 fps | Night Vision | Yes | Night Vision Type | Infrared |
| Camera | |||||||||||||||||||
| Night Vision Distance | 65.62 ft | Night Vision Distance (mm) | 20000 | Wide Dynamic Range | Yes | ||||||||||||||
| Display & Graphics | |||||||||||||||||||
| Color Supported | Color, Monochrome | Effective Camera Resolution (Pixel) | 2000000 | Maximum Video Resolution | 1920 x 1080 | Minimum Illumination (lux) | 0 | ||||||||||||
| Environmental Conditions | |||||||||||||||||||
| Maximum Operating Temperature | 131°F | Maximum Operating Temperature (°F) | 131 | Minimum Operating Temperature | 14°F | Minimum Operating Temperature (°F) | 14 | Operating Humidity | <90% RH | Storage Temperature (T-T) (°F) | -153 | ||||||||
| Exposure | |||||||||||||||||||
| Longest Shutter Speed | 2 Second | Minimum Illumination | 0 lux | Shortest Shutter Speed | 1/12,000 Second | ||||||||||||||
| Interfaces/Ports | |||||||||||||||||||
| Network (RJ-45) | Yes | ||||||||||||||||||
| Lens | |||||||||||||||||||
| Focal Length | 2.8 mm | Lens Included | Yes | Maximum Focal Length | 2.8 mm | ||||||||||||||
| Network & Communication | |||||||||||||||||||
| Remote Management | Yes | ||||||||||||||||||
| Physical Characteristics | |||||||||||||||||||
| Color | White | Color Family | White | Diameter (mm) | 110 | Form Factor | Dome | Height | 3.4" | Height (mm) | 86 | Product Color | White | Weight (Approximate) | 0.6 lb | ||||
| Product Information | |||||||||||||||||||
| Diameter | 4.33" | Mount Type | Box Mount, Ceiling Mount, Corner Mount, Gang Box Mount, Pendant Mount, Pole Mount, Wall Mount | Operating Temperature (T-T) (°F) | 14-131 | ||||||||||||||
| Projection Lens | |||||||||||||||||||
| Minimum Focal Length (mm) | 2.8 | ||||||||||||||||||
| Storage | |||||||||||||||||||
| Recording Formats | Full HD | Storage Type | Memory Card | ||||||||||||||||
| Video | |||||||||||||||||||
| Maximum Frame Rate (fps) | 30 | ||||||||||||||||||
| Miscellaneous | |||||||||||||||||||
| Features | 2 MP (1920 x 1080) resolution, 30fps at all resolutions (H.264), Built-in 2.8mm fixed lens, Day and Night (ICR), WDR (120dB), H.264, MJPEG codec supported, Multiple streaming, Hallway view, WiseStream II support, IR viewable length 20m, Micro SD/SDHC memory slot (Max. 32GB), PoE, Tampering, Motion detection, White camera body | Indoor/Outdoor | Indoor |
| Weight | 0.59 lbs |
|---|
