Genesis 45151004 12/2 Solid Plenum Fire Alarm Cable, Unshielded, FPLP, CL3P, FT6, 1000′ (304.8m), Reel,
Solid bare copper conductors
Rated for plenum, riser, and general purpose indoor installation
1000′ (304.8 m)
$580.49
Product Overview
This Genesis® cable features 2 solid 12 AWG copper conductors and a plenum rating. Choose this cable for a dependable fire alarm system wiring solution.
Main Features
- Solid bare copper conductors
- Rated for plenum, riser, and general purpose indoor installation
- 1000′ (304.8 m) reel
- Red jacket
| Specifications | |||||||||||||||||||||||||||
| Part Number | 45151004 | Packaged Quantity | 1 | Product Model | 45151004 | Product Name | 45151004 - 12 AWG 2C Sol Plenum, Red, 1000 ft. Reel | Product Type | Fire Alarm Cable | Weight (Approximate) (g) | 24493.988 | ||||||||||||||||
| Technical Information | |||||||||||||||||||||||||||
| American Wire Gauge | 12AWG | Cable Listing | CL3P, FPLP, FT6 | Cable Rating | Plenum | Conductor Count | 2 | Conductor Material | Bare Copper | Connector on First End | Bare Wire | Connector on Second End | Bare Wire | Core/Cladding Diameter | 2-Dec | Device Supported | Fire Alarm | Jacket Material | LS PVC | Number of Conductors | 2 | Number of Pairs | 1 | Shielding | No | Solid or Stranded | Solid |
| Physical Characteristics | |||||||||||||||||||||||||||
| Cable Length | 1000' | Cable Length (mm) | 304800 | Color | Red | Insulation Material | LS-PVC | Material | Bare Copper | Package Type | Reel | Weight (Approximate) | 54 lb | ||||||||||||||
| Warranty | |||||||||||||||||||||||||||
| Limited Warranty | 3 Year; 3-for-1 | ||||||||||||||||||||||||||
| Miscellaneous | |||||||||||||||||||||||||||
| Environmental Certification | RoHS | Environmentally Friendly | Yes | Indoor/Outdoor | Indoor | TAA Compliant | Yes | ||||||||||||||||||||
| Weight | 54 lbs |
|---|
