Genesis 45111001 16/2 Solid Plenum Fire Alarm Cable, Unshielded, FPLP, CL3P, FT6, 1000′ (304.8m), Reel,
Solid bare copper conductors
Rated for plenum, riser, and general purpose indoor installation
1000′ (304.8 m)
$254.99
Product Overview
This Genesis® cable features 2 solid 16 AWG copper conductors and a plenum rating. Choose this cable for a dependable fire alarm system wiring solution.
Main Features
- Solid bare copper conductors
- Rated for plenum, riser, and general purpose indoor installation
- 1000′ (304.8 m) reel
- White jacket
| Specifications | |||||||||||||||||||||||||||
| Part Number | 45111001 | Packaged Quantity | 1 | Product Model | 45111001 | Product Name | 16 AWG 2C SOL Plenum, White, 1000 ft. Reel | Product Type | Fire Alarm Cable | ||||||||||||||||||
| Technical Information | |||||||||||||||||||||||||||
| American Wire Gauge | 16AWG | Cable Listing | CL3P, FPLP, FT6 | Cable Rating | Plenum | Conductor Count | 2 | Conductor Material | Bare Copper | Connector on First End | Bare Wire | Connector on Second End | Bare Wire | Core/Cladding Diameter | 16/2 | Device Supported | Alarm, Fire Alarm | Jacket Material | LS PVC | Number of Conductors | 2 | Number of Pairs | 1 | Shielding | No | Solid or Stranded | Solid |
| Physical Characteristics | |||||||||||||||||||||||||||
| Cable Length | 1000' | Color | White | Insulation Material | LS-PVC | Material | Bare Copper | Package Type | Reel | Weight (Approximate) | 23.10 lb | ||||||||||||||||
| Warranty | |||||||||||||||||||||||||||
| Limited Warranty | 3 Year; 3-for-1 | ||||||||||||||||||||||||||
| Miscellaneous | |||||||||||||||||||||||||||
| Weight | 25 lbs |
|---|
