ELK 100 High Performance Siren Driver Module
Two Volume Levels Simultaneously
Draws Less Current Than Most Sirens
MilliMiser Lowers Current
$36.62
Product Overview
The ELK-100 Siren Driver is a great choice for residential and commercial security installations. It draws less current than most siren drivers, and offers two volume levels (example: one indoor, the other outdoor) simultaneously. Our exclusive MilliMiser™ option allows further reduction of current draw for controls that have limited alarm or auxiliary output power. The ELK-100 has two inputs, Yelp & Steady. The Steady sound overrides the Yelp. The Yelp input has our unique ComboTrigger™ feature, especially designed for controls that have a single alarm output with a pulsing option for fire or burglary. When pulsed, this channel produces a distinctive third sound pattern.
Main Features
- Two Volume Levels Simultaneously
- Draws Less Current Than Most Sirens
- MilliMiser Lowers Current Draw
- Economical – Drives Multiple Speakers
- ComboTrigger™ For Single Outputs
- Pre-Wired for easy Installation
- Lifetime Limited Warranty
| Specifications | |||||||||
| Part Number | ELK100 | Packaged Quantity | 1 | Product Model | ELK-100 | Product Name | High Performance Siren Driver Module | Product Type | Siren Driver Module |
| Technical Information | |||||||||
| Device Supported | Control Panel | ||||||||
| Physical Characteristics | |||||||||
| Color | Green | Height | 3.6" | Width | 2.8" | ||||
| Power Description | |||||||||
| Input Voltage | 14V DC | ||||||||
| Product Information | |||||||||
| Installation Type | Commercial, Residential | ||||||||
| Warranty | |||||||||
| Limited Warranty | Lifetime | ||||||||
| Miscellaneous | |||||||||
| Environmental Certification | RoHS | ||||||||
| Weight | 1 lbs |
|---|
